Liquid Silicone Production Line
-
≥1/set
USD 150,000.00
1.Introduction to Liquid Silicone Rubber (LSR)
Liquid Silicone Rubber (LSR) is a high-performance elastomer composed of silicone polymers (primarily polydimethylsiloxane, PDMS) and cross-linking agents. It is known for its exceptional thermal stability (-50°C to 250°C), chemical resistance, biocompatibility, electrical insulation, and flexibility. LSR is widely used in industries such as medical devices, automotive, electronics, baby care products, and food packaging.
Key Properties of LSR
✔ High & Low-Temperature Resistance – Stable performance from -50°C to 250°C.
✔ Biocompatibility – Meets FDA, ISO 10993, USP Class VI standards for medical applications.
✔ Soft & Elastic – Adjustable hardness (Shore A 10-80) for various applications.
✔ Chemical & UV Resistance – Resists oils, acids, ozone, and UV degradation.
✔ Excellent Flowability – Ideal for precision injection molding of complex parts.
2.LSR Manufacturing Process
LSR is typically produced using a two-part (A+B) platinum-cured addition system. The production involves the following steps:
1. Raw Material Preparation
-
Part A: Contains vinyl-terminated silicone oil, platinum catalyst, and reinforcing fillers (e.g., fumed silica).
-
Part B: Contains hydrogen-functional silicone (crosslinker), inhibitors, and pigments (if colored).
2. Mixing & Degassing
-
Parts A and B are mixed in a 1:1 ratio (varies by formulation).
-
The mixture is vacuum degassed to remove air bubbles for uniform consistency.
3. Injection Molding (LSR Molding)
-
The mixed LSR is injected into a heated mold (120-200°C) using a low-pressure injection molding machine.
-
The platinum catalyst triggers cross-linking (curing) within 10-120 seconds.
4. Post-Curing (Optional)
-
Some parts undergo post-curing (1-4 hours at 200°C) to enhance mechanical properties.
5. Quality Control & Packaging
-
Final products are tested for dimensional accuracy, hardness, tensile strength, and biocompatibility (if medical-grade).
-
Sterilization (e.g., autoclaving, gamma irradiation) may be applied for medical devices.
3.Key Materials in LSR Formulation
| Component | Function | Common Types |
|---|---|---|
| Base Polymer | Primary silicone structure | Vinyl-terminated PDMS |
| Crosslinker | Forms covalent bonds for curing | Hydrogen silicone oil (Si-H) |
| Catalyst | Accelerates curing reaction | Platinum (Pt) complex |
| Fillers | Enhances strength & stability | Fumed silica, quartz powder |
| Pigments | Adds color (if needed) | FDA-approved dyes |
| Inhibitors | Controls curing speed | Tetramethyltetravinylcyclotetrasiloxane |
TGM Chemical Machine Co., Ltd is a group enterprise. We have brands like TGM, Pengchang and Tongpeng.
We are a leader in the field of chemical machine industry, with 18 years of industry experience.
We have professional R&D design team, strong technical support, skilled production team, reliable after sales service, flexible customized solutions,
to meet your various standards and non standard equipment procurement needs. We committed to providing the complete and professional chemical equipment solutions.
We integrate, design, development, production, sales and training together.
Our products scope: Disperser, Bead Mill, Basket Mill, Mixer, emulsifier, Mixing kettles, Reactor, Filling machine, Bag filter, Pumps, Zirconium Bead, 3 roll mill, and other accessories.
Our machines help you to make ideal products: paints, coatings, inks, pigments, dyes, thinner, hardener, emulsions, varnish, spin finish, putty, glues, adhesives, viscous pastes, concrete Admixtures,
PCVC solvent cement, liquid resins, sealants, silicone sealant, lithium battery, electronic slurry&paste, pulps, silicon dioxide, liquid rubber, pesticide, liquid fertilizer, disinfectant, liquid detergent, gel,
lotions, shampoo, body wash, liquid soap, hand sanitizer, liquid wash, nail polish, creams, and so on.
We could offer individual machine or full production lines for your plants.
5. What are advantages of your factory?
1) Our factory is a leader manufacture of Chemical machine With 18 years of Industry experience. We have a lot Technology Patents & Product Patents;
2) Our factory has Professional R&D Teams, High Technical Supports, Skilled Production Team, Reliable After Sales Service, Flexible Customized Solutions;
3) Our factory is the leader of this industry, named with high and new technology enterprise;
4) Our factory has plenty of industry experience, we could offer you the complete palnt planning.
6. Who are your factory's clients? Could you list some of them?
AKZONOBEL, JUNTON, PPG, NIPPON, DABAO, BURGER, MAYDOS, RAINBOW, HITECH COATING, CHINA PAINT, CHANGJIANG COATING, TOA, LYNWON PIGMENT,
PEONY INKS, TL INKS, ZR INKS, SAKATA INKS, KINGSWOO INKS, DIC INKS, ANLI, ACHILLES, REPOW GROUP, SHINETSU ADHESIVES, JUSHI, XINGLONG PESTICIDES...
7. What certificate your factory could offer?:
CE, BSC, CNEX, ISO, patents.
8. Manufacture Processing:
Our Chemical Machines are strictly quality control at every single production step, after quality past, we will move to do next step production.
Our Chemical Machines production process: raw materials preparing-cutting/bending materials-welding-polishing-assembling-coating-testing-packing-loading.
9. Packing And Shipping:
10. FAQ:
Question: Are you a factory or a trading company? where is your factory?
Answer: We are a real factory. Our factory is in fu'an industrial zone, leliu street, shunde ditrict, foshan city, guangdong province, China.
Question: Which countries your machine sold to?
Answer: American Market: America, Canada, Mexico, Brazil;
European Market: UK, Germany, Netherlands, Bulgaria, Italy, Russia;
African Market: South Africa, Algeria, Zambia, Cameroon, Ethiopia, Uganda, Madagascar;
Asian Market: Malaysia, Indonesia, Singapore, Vietnam, Thailand, Kazakhstan, Bangladesh, Pakistan, Lebanon, Iran, Iraq, Egypt, Qatar, Turkey, Saudi Arabia, UAE;
Question: How long is your machine warranty?
Answer: 12 months free for whole machine, After a year, spare parts charges, but life-long free for consultant.
Question: How long is your lead time?
Answer: Depends on the machines you choose. Generally from 7 days to 35days. Some big machine: 45-60days.
Question: How could I know how to operate the machines?
Answer: We provide teaching video and operating manual, and 24 hours in 7 days video guidance.
Question:How long is your machine warranty?
Answer: 12 months free for whole machine, After a year, spare parts charges, but life-long free for consultant.
